This is the box that turns one 32A feed into a set of usable circuits. Take a 32A lead from a generator or site supply into the inlet, and four 16A sockets come out the other side for running separate kit, with a 32A through socket as well for sending power on to another distro elsewhere on site.
It's part of PCE's IMST range of mobile distribution boxes, designed and built in Austria to an extremely high standard, and for the price we think they're the best portable distro boxes you'll find anywhere. The case is shock-resistant polyamide with a high-grade steel folding carry handle, it's IP44 splashproof so it works outdoors as well as in, and the stackable design keeps the boxes tidy in storage. All the protection sits behind a clear hinged window, so you can see every breaker position at a glance while it runs.
What it suits
Anything that runs several pieces of equipment off one feed. Marquee bars pairing a tea urn with fridges, stage rigs spreading PA and lighting across separate circuits, catering pitches and exhibitor stands all fed from one generator. An incoming 32A 30mA RCBO protects the whole unit, and each of the four 16A outlets gets its own 16A type C MCB, so one faulty appliance trips only its own circuit. Worth knowing before you book: the 32A through socket has no breaker of its own, so it's meant for linking our other IMST distros together, and whatever you hang off it relies on the protection upstream.
We've been wiring temporary power into events across Sheffield, Rotherham, Barnsley, Doncaster and the surrounding area for over 25 years, with regular nationwide runs to venues like the NEC Birmingham and ExCeL London. If you're taking one of our larger generators with multi-outlet distribution, this is the unit that goes with it. On its own, it pairs nicely with the small 5 Kva Diesel Generator; step up to the six-outlet 32A IMST distro when you want more 16A sockets, or the three-phase 415V distro for a 400V feed. Put a cable protector anywhere a lead crosses a walkway, and ask about the Instagrid LINK 6.3kWh Electric Generator if you'd rather run silent and fume-free.
Hit the green button to add this distro to your quote and we'll get back to you the same day.
Pricing & Availability
- From £25 + VAT per day; overnight hire available for an extra £25
- This is the unit we supply when you hire our larger generators with multi-outlet distribution
- We can supply up to 25m of cabling between the supply and this distro
Specification (PCE IMST)
- Manufacturer: PCE, made in Austria
- Input: 32A 230V 2P+E IP44 appliance inlet
- Incoming protection: 32A 30mA 2P RCBO
- Outputs: 4 x 16A 230V 2P+E IP44 sockets, each on its own 16A type C MCB
- Through output: 1 x 32A 230V 2P+E IP44 socket, unprotected (anything chained from it relies on protection upstream)
- Maximum load: 32A, roughly 7kW, across all sockets combined
- Casing: shock-resistant polyamide, high-grade steel folding carry handle, stackable
- 8 modules under the clear breaker window, IP44 splashproof
- Works on any surface, indoors or out: artificial grass, hard floors, grass, concrete, mixed surfaces and wood chip are all fine
Useful With
Suitable For
| Indoors on Artificial Grass |  |
| Indoors on Hard Surface | |
| Outdoors on Concrete | |
| Outdoors on Grass | |
| Outdoors on Grass / Hard Surface Mix | |
| Outdoors on Hard Surface | |
| Outdoors on Wood Chip | |
